Name: Geopera Satellite Imagery Solutions
Brand: Geopera

Analysis-ready satellite imagery

Let us handle the processing. Get orthorectified, pansharpened, colour-balanced and mosaiced imagery from one automated preprocessing chain, Legato, included with every order.

View available data View pricing

Seamless colour-matched farmland mosaic seen from above

Right now, people are using Geopera's imagery to

measure carbon across huge landscapes

Explore data now on our portal

The pipeline

How we process every order

Every step below runs on this real order as you scroll — the same automated chain behind every delivery. Nothing manual, nothing skipped.

Captures come off the downlink as Level-1 products — 11-bit pixels in sensor geometry, with RPCs, ephemeris and calibration coefficients intact. Nothing is resampled until the geometry is solved.

scenes in block

1 / 3
gsd

0.30 m
bands

PAN + 4 × MS
bit depth

11-bit
Tie points are matched across every overlap, then a bundle block adjustment solves all captures into one relative frame. Scene-to-scene drift collapses to sub-pixel before anything else happens.

tie points

14,202
relative rmse

0.31 px
solution

bundle block
Refined RPCs are anchored to ground control and a DEM, and every pixel is map-projected. Supply GCPs or a base layer and the block adjusts to it — your survey is the reference, not the satellite's.

control residual

0.24 m
reference

your GCPs
dem

1 m DSM
crs

EPSG:32633
The panchromatic band carries spatial detail; the multispectral bands carry the radiometry. Fusion injects PAN detail into each MS band while preserving band ratios — downstream indices stay valid.

pan

0.30 m
ms

1.2 m · 4-band
fused

0.30 m · 4-band
spectral ratios

preserved
Top-of-atmosphere radiance becomes surface reflectance: aerosol optical depth is estimated per scene, then path radiance, haze and adjacency effects are modelled out. Values become physically meaningful — comparable across dates and sensors.

input

TOA radiance
output

BOA reflectance
aod @ 550 nm

0.18
sun elevation

52.3°
Clouds, cirrus and their projected shadows are detected per pixel. The masks do more than flag bad data — they tell the mosaic engine which scene can contribute clean pixels where.

cloud

4.6 %
shadow

1.9 %
clean coverage across block

100 %
Cutlines are solved as least-cost paths — through low-contrast terrain, around masked clouds, never across structures. Watch each line detour: the area it cuts off is re-sourced from the scene that is clean there.

cost terms

gradient · cloud mask
cloud crossings

0
route

least-cost
Scene radiometry is normalised across the block, seams feathered, and the result written as one continuous surface with no visible joins. That is Legato: every stage above tied into one automated flow — nothing manual between them, nothing skipped — and the seamless, join-free mosaic is the proof the whole chain ran. Automated QC signs off geometry, radiometry and coverage before it ships.

seam Δe

0.4
qc · geometry

pass
qc · radiometry

pass
process

Legato · gapless
delivery

COG · tiles · STAC

01 / 08

Source capture & ingest

Captures come off the downlink as Level-1 products — 11-bit pixels in sensor geometry, with RPCs, ephemeris and calibration coefficients intact. Nothing is resampled until the geometry is solved.

scenes in block: 1 / 3
gsd: 0.30 m
bands: PAN + 4 × MS
bit depth: 11-bit

Deliverables

Every order ships the full chain, raw to mosaic.

Not just the finished mosaic: every level the pipeline produces lands in your delivery, cloud-native, by download or WMTS streaming.

RAW

Raw source data

Original vendor scenes as captured (PAN + MSS), including RPCs and sensor metadata.

Orthorectified scenes

16-bit per-scene imagery, terrain- and sensor-geometry corrected (DEM + RPC), map-projected and tie-point aligned. Separate Pan and Multi products.

Surface reflectance scenes

16-bit atmospherically corrected surface reflectance (scaled ×20,000), per scene. Separate Pan and Multi products.

Pansharpened, visual

8-bit natural-colour pansharpened scenes, tone- and colour-balanced and sharpened for visual analysis.

Pansharpened, analytic

16-bit radiometrically faithful pansharpened scenes retaining surface reflectance (scaled ×20,000).

Mosaics

Seamless, colour-balanced, cloud-masked mosaics of the full AOI along optimised seamlines: pansharpened visual (8-bit), pansharpened analytic (16-bit), and Pan and Multi surface reflectance (16-bit).

Metadata & QA

Imagery Processing Report (PDF): sensor, capture, coverage and per-level processing summary. Mosaic seamlines and cloud masks as GeoJSON, in the delivery's 00_Metadata folder.

Download the capability statement (PDF)

TASKING

Instant pricing, delivery in under 24 hours

An easier way to order new imagery. Place tasking orders, get an instant price estimate, and download imagery into your workflow.

View pricing

Archive imagery search results beside a map with a drawn area of interest and its price

Archive imagery from 100+ sensors

Access archive imagery from 100+ sensors, at resolutions from 30 cm. Filter by resolution, acquisition mode, and processing level.

View our sensors

See a processed order over your own area

Apply for a processed sample over your own area of interest, delivered with the QC report behind it, or talk to our team about your satellite imagery needs.

Apply for a sample Talk to sales
